DDTH-00010-V01.03

Download the PEP PDF Extrapolation Rules
Name of the PEP
ALEZIO-S
Trademark / Owner
DE DIETRICH
BDR THERMEA GROUP
Collective PEP
No
Product classification
  • Heating, ventilation and air conditioning equipement
  • Heating and/or air conditioning and/or hot water heating
  • Domestic heat pumps
  • Air/Water
Date of publication
2020/08/03
Date of end of validity
2025/08/03
Date of verification
-
PCR
PEP-PCR-ed3-2015 04 02
PSR
PSR-0013-ed2-2019 12 06
Use lifte time
17 years
Reference Product
ALEZIO S6MR/EM Référence 7746792
Energy model used
France
Total mass
88.9 kg
Constitution
Plastic
71.00 %
Metal
8.10 %
Other
20.90 %
Covered products or brand by text
ALEZIO S 4.5 MR/H - référence : 7746777 ALEZIO S 4.5 MR/EM - référence : 7746790 ALEZIO S 6 MR/H - référence : 7746791 ALEZIO S 8 MR/H - référence : 7746793 ALEZIO S 8 MR/EM - référence : 7746794 ALEZIO S 11 MR/H - référence : 7746795 ALEZIO S 11 MR/EM - référence : 7746796 ALEZIO S 11 TR/H - référence : 7746797 ALEZIO S 11 TR/EM - référence : 7746798 ALEZIO S 16 MR/H - référence : 7746799 ALEZIO S 16 MR/EM - référence : 7746800 ALEZIO S 16 TR/H - référence : 7746801 ALEZIO S 16 TR/EM - référence : 7746802
Functional Unit
1 kW
Description
Produire 1 kW de chauffage, selon le scénario d’usage approprié défini dans la norme EN14825 et pendant une durée de vie de référence de 17 ans du produit
Indicator Unit Total Manufacturing Distribution Installation Use End of Life Use
B1		 Maintenance
B2		 Repair
B3		 Replacement
B4		 Refurbishment
B5		 Operational energy use
B6		 Operational water use
B7		 Benefits and loads beyond the system boundaries
D
Global warming kg.eq.CO2 1.67E+3 1.84E+2 1.23E+0 9.68E+0 1.39E+3 8.52E+1 2.31E+2 6.69E+1 00E+0 00E+0 00E+0 1.09E+3 00E+0 0
Ozone depletion kg.eq.CFC-11 1.63E-3 1.6E-5 2.49E-9 8E-7 1.61E-3 1.89E-8 1.86E-8 4.45E-5 00E+0 00E+0 00E+0 1.56E-3 00E+0 0
Acidification of soil and water kg.eq.SO2 4.69E+0 4.41E-1 5.52E-3 2.1E-2 4.22E+0 2.94E-3 1.95E-4 1.46E-1 00E+0 00E+0 00E+0 4.07E+0 00E+0 0
Water eutrophication kg.eq.P04 3- 5.28E-1 8.91E-2 1.27E-3 1.91E-2 4.11E-1 7.86E-3 5.55E-5 3.98E-2 00E+0 00E+0 00E+0 3.71E-1 00E+0 0
Photochemical Ozone formation kg.eq.C2H4 3.62E-1 4.17E-2 3.92E-4 2.66E-3 3.17E-1 2.19E-4 3.4E-5 8.17E-2 00E+0 00E+0 00E+0 2.36E-1 00E+0 0
Depletion of abiotic resources - elements kg.eq.Sb 1.89E-2 1.83E-2 4.92E-8 2.47E-5 5.34E-4 2.15E-8 1.18E-8 2.75E-8 00E+0 00E+0 00E+0 5.34E-4 00E+0 0
Depletion of abiotic resources - fossil fuels MJ 1.52E+4 1.67E+3 1.73E+1 8.04E+1 1.34E+4 4.23E+0 6.48E+0 8.06E+2 00E+0 00E+0 00E+0 1.26E+4 00E+0 0
Water pollution m³ 8.15E+4 1.49E+4 2.02E+2 1.09E+3 6.47E+4 5.76E+2 1.21E+1 9.31E+3 00E+0 00E+0 00E+0 5.54E+4 00E+0 0
Air pollution m³ 9.94E+4 2.45E+4 5.04E+1 8.95E+2 7.08E+4 3.16E+3 8.75E+3 2.56E+4 00E+0 00E+0 00E+0 3.65E+4 00E+0 0
Use of renewable primary energy, excluding renewable primary energy resources used as raw materials MJ 7.27E+3 2.88E+1 2.32E-2 00E+0 7.24E+3 5.18E-2 3.3E-4 1.15E-2 00E+0 00E+0 00E+0 7.24E+3 00E+0 0
Use of renewable primary energy resources used as raw materials MJ 5.43E+1 4.96E+1 00E+0 4.73E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Total use of renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 7.32E+3 7.84E+1 2.32E-2 3.18E+0 7.24E+3 5.18E-2 3.3E-4 1.15E-2 00E+0 00E+0 00E+0 7.24E+3 00E+0 0
Use of non-renewable primary energy, excluding non-renewable primary energy resources used as raw materials MJ 9.74E+4 3.61E+3 1.74E+1 3.67E+2 9.34E+4 4.92E+0 2.1E+0 8.12E+2 00E+0 00E+0 00E+0 9.26E+4 00E+0 0
Use of non-renewable primary energy resources used as raw materials MJ 1.49E+2 1.38E+2 00E+0 6.35E+0 4.97E+0 00E+0 4.97E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Total use of non-renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 9.76E+4 3.75E+3 1.74E+1 3.73E+2 9.34E+4 4.92E+0 7.08E+0 8.12E+2 00E+0 00E+0 00E+0 9.26E+4 00E+0 0
Use of secondary materials kg 1.32E+1 1.18E+1 00E+0 1.39E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Use of renewable secondary fuels MJ 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Use of non-renewable secondary fuels MJ 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Net use of fresh water m³ 2.59E+4 1.22E+1 1.1E-4 1.17E+0 2.59E+4 7.33E-3 5.86E-4 8.35E-2 00E+0 00E+0 00E+0 2.59E+4 00E+0 0
Hazardous waste disposed of kg 1.92E+2 1.82E+2 00E+0 8.42E+0 2.17E+0 1.87E-3 4.89E-3 9.76E-2 00E+0 00E+0 00E+0 2.06E+0 00E+0 0
Non-hazardous waste disposed of kg 2.4E+3 1.34E+2 4.37E-2 1.01E+1 2.24E+3 1.39E+1 2.12E-3 1.29E-1 00E+0 00E+0 00E+0 2.24E+3 00E+0 0
Radioactive waste disposed of kg 3.31E+1 3.24E-2 3.11E-5 2.37E-3 3.31E+1 6.32E-5 5.88E-6 1.28E-2 00E+0 00E+0 00E+0 3.3E+1 00E+0 0
Components for re-use kg 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Materials for recycling kg 8.66E+0 1.13E+0 00E+0 2.95E+0 00E+0 4.58E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Materials for energy recovery kg 5.25E+0 7.96E-8 00E+0 3.57E-1 00E+0 4.89E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Exported energy MJ by energy vector 3.16E-1 3.21E-2 00E+0 3.3E-2 00E+0 2.51E-1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Total use of primary energy during the life cycle MJ 1.05E+5 3.83E+3 1.74E+1 3.76E+2 1.01E+5 4.97E+0 7.08E+0 8.12E+2 00E+0 00E+0 00E+0 9.99E+4 00E+0 0
Functional Unit
1 unit
Description
Pompe à chaleur air/eau d’une puissance de XX* kW assurant la fonction de fournir de la chaleur à un logement individuel pour une durée de vie de référence de 17 ans (la puissance est à ajuster en fonction du produit considéré de la gamme)
Indicator Unit Total Manufacturing Distribution Installation Use End of Life Use
B1		 Maintenance
B2		 Repair
B3		 Replacement
B4		 Refurbishment
B5		 Operational energy use
B6		 Operational water use
B7		 Benefits and loads beyond the system boundaries
D
Global warming kg.eq.CO2 6.02E+3 6.61E+2 4.42E+0 3.49E+1 5.01E+3 3.07E+2 8.32E+2 2.41E+2 00E+0 00E+0 00E+0 3.94E+3 00E+0 0
Ozone depletion kg.eq.CFC-11 5.85E-3 5.77E-5 8.96E-9 2.88E-6 5.79E-3 6.79E-8 6.7E-8 1.6E-4 00E+0 00E+0 00E+0 5.63E-3 00E+0 0
Acidification of soil and water kg.eq.SO2 1.69E+1 1.59E+0 1.99E-2 7.54E-2 1.52E+1 1.06E-2 7.03E-4 5.25E-1 00E+0 00E+0 00E+0 1.47E+1 00E+0 0
Water eutrophication kg.eq.P04 3- 1.9E+0 3.21E-1 4.57E-3 6.89E-2 1.48E+0 2.83E-2 2E-4 1.43E-1 00E+0 00E+0 00E+0 1.34E+0 00E+0 0
Photochemical Ozone formation kg.eq.C2H4 1.3E+0 1.5E-1 1.41E-3 9.59E-3 1.14E+0 7.89E-4 1.23E-4 2.94E-1 00E+0 00E+0 00E+0 8.48E-1 00E+0 0
Depletion of abiotic resources - elements kg.eq.Sb 6.8E-2 6.59E-2 1.77E-7 8.9E-5 1.92E-3 7.73E-8 4.26E-8 9.9E-8 00E+0 00E+0 00E+0 1.92E-3 00E+0 0
Depletion of abiotic resources - fossil fuels MJ 5.46E+4 6E+3 6.21E+1 2.89E+2 4.82E+4 1.52E+1 2.33E+1 2.9E+3 00E+0 00E+0 00E+0 4.53E+4 00E+0 0
Water pollution m³ 2.93E+5 5.36E+4 7.27E+2 3.92E+3 2.33E+5 2.08E+3 4.37E+1 3.35E+4 00E+0 00E+0 00E+0 1.99E+5 00E+0 0
Air pollution m³ 3.58E+5 8.84E+4 1.81E+2 3.22E+3 2.55E+5 1.14E+4 3.15E+4 9.2E+4 00E+0 00E+0 00E+0 1.31E+5 00E+0 0
Use of renewable primary energy, excluding renewable primary energy resources used as raw materials MJ 2.62E+4 1.04E+2 8.34E-2 00E+0 2.61E+4 1.87E-1 1.19E-3 4.14E-2 00E+0 00E+0 00E+0 2.61E+4 00E+0 0
Use of renewable primary energy resources used as raw materials MJ 1.96E+2 1.79E+2 00E+0 1.7E+1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Total use of renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 2.64E+4 2.82E+2 8.34E-2 1.15E+1 2.61E+4 1.87E-1 1.19E-3 4.14E-2 00E+0 00E+0 00E+0 2.61E+4 00E+0 0
Use of non-renewable primary energy, excluding non-renewable primary energy resources used as raw materials MJ 3.51E+5 1.3E+4 6.25E+1 1.32E+3 3.36E+5 1.77E+1 7.58E+0 2.92E+3 00E+0 00E+0 00E+0 3.33E+5 00E+0 0
Use of non-renewable primary energy resources used as raw materials MJ 5.36E+2 4.95E+2 00E+0 2.29E+1 1.79E+1 00E+0 1.79E+1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Total use of non-renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 3.51E+5 1.35E+4 6.25E+1 1.34E+3 3.36E+5 1.77E+1 2.55E+1 2.92E+3 00E+0 00E+0 00E+0 3.33E+5 00E+0 0
Use of secondary materials kg 4.73E+1 4.24E+1 00E+0 4.99E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Use of renewable secondary fuels MJ 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Use of non-renewable secondary fuels MJ 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Net use of fresh water m³ 9.34E+4 4.38E+1 3.96E-4 4.21E+0 9.33E+4 2.64E-2 2.11E-3 3E-1 00E+0 00E+0 00E+0 9.33E+4 00E+0 0
Hazardous waste disposed of kg 6.92E+2 6.54E+2 00E+0 3.03E+1 7.8E+0 6.73E-3 1.76E-2 3.51E-1 00E+0 00E+0 00E+0 7.43E+0 00E+0 0
Non-hazardous waste disposed of kg 8.63E+3 4.82E+2 1.57E-1 3.63E+1 8.06E+3 4.99E+1 7.64E-3 4.66E-1 00E+0 00E+0 00E+0 8.06E+3 00E+0 0
Radioactive waste disposed of kg 1.19E+2 1.17E-1 1.12E-4 8.55E-3 1.19E+2 2.27E-4 2.12E-5 4.62E-2 00E+0 00E+0 00E+0 1.19E+2 00E+0 0
Components for re-use kg 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Materials for recycling kg 3.12E+1 4.06E+0 00E+0 1.06E+1 00E+0 1.65E+1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Materials for energy recovery kg 1.89E+1 2.87E-7 00E+0 1.29E+0 00E+0 1.76E+1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Exported energy MJ by energy vector 1.14E+0 1.15E-1 00E+0 1.19E-1 00E+0 9.04E-1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 0
Total use of primary energy during the life cycle MJ 3.78E+5 1.38E+4 6.25E+1 1.35E+3 3.62E+5 1.79E+1 2.55E+1 2.92E+3 00E+0 00E+0 00E+0 3.59E+5 00E+0 0
