SAUN-00001-V01.01

Download the PEP PDF
Name of the PEP
Pompe à chaleur air/eau Saunier Duval GeniaSet Max assurant le chauffage et l'eau chaude sanitaire accumulée
Trademark / Owner
SAUNIER DUVAL
SAUNIER DUVAL EAU CHAUDE CHAUFFAGE (SDECC)
Collective PEP
No
Product classification
  • Heating, ventilation and air conditioning equipement
  • Heating and/or air conditioning and/or hot water heating
  • Domestic heat pumps
  • Air/Water
Geographical validity area
FRA
Date of publication
2024/01/01
Date of end of validity
2029/01/01
Date of verification
2024/01/26
PCR
PEP-PCR-ed4-2021 09 06
PSR
PSR-0013-ed3-2023 06 06
Use lifte time
17 years
Reference Product
GeniaSet Max 5 - 230 V
Energy model used
France et Slovaquie
Total mass
298.5 kg
Constitution
Plastic
11.10 %
33.13400 kg
Metal
75.40 %
225.06900 kg
Other
13.50 %
40.29800 kg
Covered products by list
- 0010031692 + 0010036670
- 0010031693 + 0010036670
- 0010031695 + 0010036670
- 0010031696 + 0010036670
- 0010031697 + 0010036670
- 0010031698 + 0010036670
- 0010031699 + 0010036670
- GeniaSet Max 12 - 230 V
- GeniaSet Max 12 - 400 V
- GeniaSet Max 15 - 230 V
- GeniaSet Max 15 - 400 V
- GeniaSet Max 4 - 230 V
- GeniaSet Max 8 - 230 V
Covered products or brand by text
0010031692 + 0010036670 - 0010031693 + 0010036670 - 0010031695 + 0010036670 -0010031696 + 0010036670 - 0010031697 + 0010036670 - 0010031698 + 0010036670 - 0010031699 + 0010036670
Functional Unit
1 kW
Description
Produire 1 kW de chauffage ainsi que la production d’eau chaude sanitaire, selon le scénario d'usage de référence et pendant la durée de vie de référence de 17 ans du produit
Extrapolation Rules
Regles d'extrapolation détaillée dans le PEP
Indicator Unit Total Manufacturing Distribution Installation Use End of Life Use
B1		 Maintenance
B2		 Repair
B3		 Replacement
B4		 Refurbishment
B5		 Operational energy use
B6		 Operational water use
B7		 Benefits and loads beyond the system boundaries
D
Climate change - total kg.eq.CO2 1.39E+3 3.36E+2 2.34E+1 1.68E+1 9.73E+2 3.67E+1 2.29E-4 1.68E+1 00E+0 00E+0 00E+0 9.56E+2 00E+0 -1.2E+2
Climate change - fossil fuels kg.eq.CO2 1.38E+3 3.46E+2 2.33E+1 4.01E+0 9.69E+2 3.48E+1 2.29E-4 1.68E+1 00E+0 00E+0 00E+0 9.52E+2 00E+0 -1.2E+2
Climate change - biogenics kg.eq.CO2 8.35E+0 -1.01E+1 7.52E-3 1.28E+1 3.75E+0 1.89E+0 00E+0 7.87E-3 00E+0 00E+0 00E+0 3.74E+0 00E+0 5.98E-1
Climate change - land use and land use transformation kg.eq.CO2 1.54E+0 8.14E-1 1.16E-2 1.36E-2 6.64E-1 3.64E-2 00E+0 6.33E-3 00E+0 00E+0 00E+0 6.58E-1 00E+0 -0.37E+0
Ozone depletion kg.eq.CFC-11 6.59E-5 2.42E-5 5.08E-7 1.07E-7 4.06E-5 4.1E-7 00E+0 1.12E-6 00E+0 00E+0 00E+0 3.95E-5 00E+0 -2.24E-6
Acidification (AP) mole.eq.H+ 1.06E+1 3.36E+0 5.1E-2 9.6E-3 6.76E+0 4.13E-1 00E+0 8.57E-2 00E+0 00E+0 00E+0 6.67E+0 00E+0 -1.02E+0
Freshwater eutrophication kg.eq.P 8.25E-2 4.89E-2 1.9E-4 6.89E-5 3.13E-2 2.05E-3 00E+0 4.05E-4 00E+0 00E+0 00E+0 3.09E-2 00E+0 -0.01E+0
Marine aquatic eutrophication kg.eq.N 1.58E+0 5.43E-1 1.26E-2 4.87E-3 9.82E-1 3.62E-2 00E+0 1.48E-2 00E+0 00E+0 00E+0 9.68E-1 00E+0 -0.12E+0
Terrestrial eutrophication mole.eq.N 1.84E+1 7.13E+0 1.31E-1 2.79E-2 1.07E+1 4.16E-1 00E+0 1.47E-1 00E+0 00E+0 00E+0 1.06E+1 00E+0 -1.46E+0
Photochemical ozone formation kg.eq.NMVOC 6.1E+0 2.15E+0 7.92E-2 1.51E-2 3.72E+0 1.39E-1 3.4E-3 1.21E-1 00E+0 00E+0 00E+0 3.6E+0 00E+0 -0.6E+0
Depletion of abiotic resources - elements kg.eq.Sb 8.63E-2 3.68E-2 7.82E-5 6.64E-6 4.52E-2 4.25E-3 00E+0 1.87E-4 00E+0 00E+0 00E+0 4.5E-2 00E+0 -0.01E+0
Depletion of abiotic resources - fossil fuels MJ 1.35E+5 4.29E+3 3.32E+2 6.27E+1 1.3E+5 4.01E+2 00E+0 6.59E+2 00E+0 00E+0 00E+0 1.3E+5 00E+0 -1.38E+3
Water requirement m³.eq.deprivation worldwide 4.7E+2 9.55E+1 1.37E+0 6.02E-1 3.55E+2 1.68E+1 00E+0 1.44E+0 00E+0 00E+0 00E+0 3.54E+2 00E+0 -3.06E+1
Emission of fine particles incidence of diseases 7.83E-5 3.05E-5 1.74E-6 1.41E-7 4.31E-5 2.82E-6 00E+0 5.16E-6 00E+0 00E+0 00E+0 3.8E-5 00E+0 -9.63E-6
Ionizing radiation, human health kBq.eq.U235 1.3E+3 8.29E+0 1.68E-1 5.14E-2 1.29E+3 2.18E+0 00E+0 1.92E-1 00E+0 00E+0 00E+0 1.29E+3 00E+0 -2.68E+0
Ecotoxicity (fresh water) CTUe 1.96E+4 1.07E+4 1.64E+2 3.75E+1 8.22E+3 5.3E+2 3.74E-5 2.79E+2 00E+0 00E+0 00E+0 7.94E+3 00E+0 -1.11E+3
Human toxicity, carcinogenic effects CTUh 3.64E-6 1.44E-6 1.06E-8 4.44E-9 1.18E-6 1.01E-6 00E+0 3.92E-8 00E+0 00E+0 00E+0 1.14E-6 00E+0 -7.21E-7
Human toxicity, non-carcinogenic effects CTUh 7.71E-5 2.15E-5 2.35E-7 3.05E-8 4.97E-5 5.52E-6 9.59E-12 3.2E-7 00E+0 00E+0 00E+0 4.94E-5 00E+0 -8.79E-6
Impacts related to land use/soil quality - 1.01E+4 3.11E+3 2E+2 1.43E+1 6.55E+3 2.35E+2 00E+0 5.21E+1 00E+0 00E+0 00E+0 6.49E+3 00E+0 -5.76E+2
Use of renewable primary energy, excluding renewable primary energy resources used as raw materials MJ 1.18E+4 7.36E+2 5.21E+0 3.51E+1 1.1E+4 5.96E+1 00E+0 6.36E+0 00E+0 00E+0 00E+0 1.1E+4 00E+0 -2.18E+2
Use of renewable primary energy resources used as raw materials MJ 8.95E+1 1.22E+2 00E+0 -3.26E+1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -6.6E+0
Total use of renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 1.19E+4 8.58E+2 5.21E+0 2.45E+0 1.1E+4 5.96E+1 00E+0 6.36E+0 00E+0 00E+0 00E+0 1.1E+4 00E+0 -2.24E+2
Use of non-renewable primary energy, excluding non-renewable primary energy resources used as raw materials MJ 1.35E+5 4.04E+3 3.32E+2 8.22E+1 1.3E+5 5.11E+2 00E+0 6.59E+2 00E+0 00E+0 00E+0 1.3E+5 00E+0 -1.36E+3
Use of non-renewable primary energy resources used as raw materials MJ 1.19E+2 2.49E+2 00E+0 -1.95E+1 00E+0 -1.1E+2 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -1.73E+1
Total use of non-renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 1.35E+5 4.29E+3 3.32E+2 6.27E+1 1.3E+5 4.01E+2 00E+0 6.59E+2 00E+0 00E+0 00E+0 1.3E+5 00E+0 -1.38E+3
Net use of fresh water m³ 4.11E+1 3.24E+0 4.76E-2 2.18E-2 3.73E+1 5.21E-1 00E+0 5.06E-2 00E+0 00E+0 00E+0 3.72E+1 00E+0 -1.23E+0
Total use of primary energy during the life cycle MJ 1.47E+5 5.14E+3 3.37E+2 6.52E+1 1.41E+5 4.6E+2 00E+0 6.66E+2 00E+0 00E+0 00E+0 1.41E+5 00E+0 -1.6E+3
Hazardous waste disposed of kg 1.68E+2 9.32E+1 3.2E-1 1.84E-1 5.93E+1 1.48E+1 00E+0 4.3E-1 00E+0 00E+0 00E+0 5.88E+1 00E+0 -4.54E+1
Non-hazardous waste disposed of kg 2.7E+3 1.07E+3 1.91E+1 5.95E+0 1.47E+3 1.31E+2 00E+0 1.22E+1 00E+0 00E+0 00E+0 1.45E+3 00E+0 -2.54E+2
Radioactive waste disposed of kg 1.69E+0 5.54E-3 1.09E-4 3.95E-5 1.68E+0 1.75E-3 00E+0 1.18E-4 00E+0 00E+0 00E+0 1.68E+0 00E+0 -0E+0
Materials for recycling kg 4.3E+1 00E+0 00E+0 1.88E+0 1.35E-1 4.1E+1 00E+0 1.35E-1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0
Materials for energy recovery kg 5.83E+0 00E+0 00E+0 2.8E+0 00E+0 3.03E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0
Biogenic carbon content of the associated packaging kg of C 3.35E+0 3.35E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0
Functional Unit
1 unit
Description
Assurer le chauffage et la production d’eau chaude sanitaire à l’aide de la pompe à chaleur GeniaSet Max 5 de 4,45 kW pour une durée de vie de référence de 17 ans du produit
Extrapolation Rules
Disponible dans la fiche PEP
Indicator Unit Total Manufacturing Distribution Installation Use End of Life Use
B1		 Maintenance
B2		 Repair
B3		 Replacement
B4		 Refurbishment
B5		 Operational energy use
B6		 Operational water use
B7		 Benefits and loads beyond the system boundaries
D
Climate change - total kg.eq.CO2 6.17E+3 1.5E+3 1.04E+2 7.48E+1 4.33E+3 1.64E+2 1.02E-3 7.49E+1 00E+0 00E+0 00E+0 4.26E+3 00E+0 -5.34E+2
Climate change - fossil fuels kg.eq.CO2 6.13E+3 1.54E+3 1.04E+2 1.79E+1 4.31E+3 1.55E+2 1.02E-3 7.48E+1 00E+0 00E+0 00E+0 4.24E+3 00E+0 -5.35E+2
Climate change - biogenics kg.eq.CO2 3.71E+1 -4.48E+1 3.35E-2 5.68E+1 1.67E+1 8.41E+0 00E+0 3.5E-2 00E+0 00E+0 00E+0 1.67E+1 00E+0 2.66E+0
Climate change - land use and land use transformation kg.eq.CO2 6.85E+0 3.62E+0 5.17E-2 6.03E-2 2.95E+0 1.62E-1 00E+0 2.82E-2 00E+0 00E+0 00E+0 2.93E+0 00E+0 -1.63E+0
Ozone depletion kg.eq.CFC-11 2.93E-4 1.08E-4 2.26E-6 4.74E-7 1.81E-4 1.82E-6 00E+0 4.98E-6 00E+0 00E+0 00E+0 1.76E-4 00E+0 -9.97E-6
Acidification (AP) mole.eq.H+ 4.71E+1 1.5E+1 2.27E-1 4.27E-2 3.01E+1 1.84E+0 00E+0 3.81E-1 00E+0 00E+0 00E+0 2.97E+1 00E+0 -4.55E+0
Freshwater eutrophication kg.eq.P 3.67E-1 2.17E-1 8.44E-4 3.06E-4 1.39E-1 9.1E-3 00E+0 1.8E-3 00E+0 00E+0 00E+0 1.38E-1 00E+0 -0.03E+0
Marine aquatic eutrophication kg.eq.N 7.02E+0 2.41E+0 5.59E-2 2.17E-2 4.37E+0 1.61E-1 00E+0 6.57E-2 00E+0 00E+0 00E+0 4.31E+0 00E+0 -0.55E+0
Terrestrial eutrophication mole.eq.N 8.2E+1 3.17E+1 5.82E-1 1.24E-1 4.77E+1 1.85E+0 00E+0 6.55E-1 00E+0 00E+0 00E+0 4.7E+1 00E+0 -6.48E+0
Photochemical ozone formation kg.eq.NMVOC 2.72E+1 9.55E+0 3.52E-1 6.71E-2 1.66E+1 6.18E-1 1.51E-2 5.39E-1 00E+0 00E+0 00E+0 1.6E+1 00E+0 -2.67E+0
Depletion of abiotic resources - elements kg.eq.Sb 3.84E-1 1.64E-1 3.48E-4 2.96E-5 2.01E-1 1.89E-2 00E+0 8.33E-4 00E+0 00E+0 00E+0 2E-1 00E+0 -0.03E+0
Depletion of abiotic resources - fossil fuels MJ 6.03E+5 1.91E+4 1.48E+3 2.79E+2 5.8E+5 1.78E+3 00E+0 2.93E+3 00E+0 00E+0 00E+0 5.77E+5 00E+0 -6.12E+3
Water requirement m³.eq.deprivation worldwide 2.09E+3 4.25E+2 6.08E+0 2.68E+0 1.58E+3 7.48E+1 00E+0 6.4E+0 00E+0 00E+0 00E+0 1.58E+3 00E+0 -1.36E+2
Emission of fine particles incidence of diseases 3.48E-4 1.36E-4 7.72E-6 6.27E-7 1.92E-4 1.25E-5 00E+0 2.29E-5 00E+0 00E+0 00E+0 1.69E-4 00E+0 -4.29E-5
Ionizing radiation, human health kBq.eq.U235 5.78E+3 3.69E+1 7.48E-1 2.29E-1 5.74E+3 9.7E+0 00E+0 8.56E-1 00E+0 00E+0 00E+0 5.74E+3 00E+0 -1.19E+1
Ecotoxicity (fresh water) CTUe 8.74E+4 4.75E+4 7.29E+2 1.67E+2 3.66E+4 2.36E+3 1.67E-4 1.24E+3 00E+0 00E+0 00E+0 3.53E+4 00E+0 -4.92E+3
Human toxicity, carcinogenic effects CTUh 1.62E-5 6.39E-6 4.74E-8 1.98E-8 5.25E-6 4.5E-6 00E+0 1.74E-7 00E+0 00E+0 00E+0 5.08E-6 00E+0 -3.21E-6
Human toxicity, non-carcinogenic effects CTUh 3.43E-4 9.59E-5 1.05E-6 1.36E-7 2.21E-4 2.46E-5 4.27E-11 1.43E-6 00E+0 00E+0 00E+0 2.2E-4 00E+0 -3.91E-5
Impacts related to land use/soil quality - 4.5E+4 1.38E+4 8.92E+2 6.35E+1 2.91E+4 1.04E+3 00E+0 2.32E+2 00E+0 00E+0 00E+0 2.89E+4 00E+0 -2.56E+3
Use of renewable primary energy, excluding renewable primary energy resources used as raw materials MJ 5.27E+4 3.27E+3 2.32E+1 1.56E+2 4.89E+4 2.65E+2 00E+0 2.83E+1 00E+0 00E+0 00E+0 4.89E+4 00E+0 -9.7E+2
Use of renewable primary energy resources used as raw materials MJ 3.98E+2 5.43E+2 00E+0 -1.45E+2 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -2.94E+1
Total use of renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 5.31E+4 3.82E+3 2.32E+1 1.09E+1 4.89E+4 2.65E+2 00E+0 2.83E+1 00E+0 00E+0 00E+0 4.89E+4 00E+0 -9.99E+2
Use of non-renewable primary energy, excluding non-renewable primary energy resources used as raw materials MJ 6.02E+5 1.8E+4 1.48E+3 3.66E+2 5.8E+5 2.27E+3 00E+0 2.93E+3 00E+0 00E+0 00E+0 5.77E+5 00E+0 -6.04E+3
Use of non-renewable primary energy resources used as raw materials MJ 5.31E+2 1.11E+3 00E+0 -8.68E+1 00E+0 -4.91E+2 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -7.68E+1
Total use of non-renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 6.03E+5 1.91E+4 1.48E+3 2.79E+2 5.8E+5 1.78E+3 00E+0 2.93E+3 00E+0 00E+0 00E+0 5.77E+5 00E+0 -6.12E+3
Net use of fresh water m³ 1.83E+2 1.44E+1 2.12E-1 9.71E-2 1.66E+2 2.32E+0 00E+0 2.25E-1 00E+0 00E+0 00E+0 1.66E+2 00E+0 -5.49E+0
Total use of primary energy during the life cycle MJ 6.56E+5 2.29E+4 1.5E+3 2.9E+2 6.29E+5 2.05E+3 00E+0 2.96E+3 00E+0 00E+0 00E+0 6.26E+5 00E+0 -7.11E+3
Hazardous waste disposed of kg 7.46E+2 4.15E+2 1.42E+0 8.19E-1 2.64E+2 6.58E+1 00E+0 1.92E+0 00E+0 00E+0 00E+0 2.62E+2 00E+0 -2.02E+2
Non-hazardous waste disposed of kg 1.2E+4 4.78E+3 8.52E+1 2.65E+1 6.52E+3 5.82E+2 00E+0 5.41E+1 00E+0 00E+0 00E+0 6.47E+3 00E+0 -1.13E+3
Radioactive waste disposed of kg 7.52E+0 2.47E-2 4.85E-4 1.76E-4 7.49E+0 7.79E-3 00E+0 5.23E-4 00E+0 00E+0 00E+0 7.49E+0 00E+0 -0.01E+0
Materials for recycling kg 1.91E+2 00E+0 00E+0 8.37E+0 6E-1 1.82E+2 00E+0 6E-1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0
Materials for energy recovery kg 2.59E+1 00E+0 00E+0 1.25E+1 00E+0 1.35E+1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0
Biogenic carbon content of the associated packaging kg of C 1.49E+1 1.49E+1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0
