ORON-00005-V01.01

Download the PEP PDF Extrapolation Rules
Name of the PEP
ORONA NEXT SMART/SMART+ S19
Trademark / Owner
ORONA S.COOP.
ORONA
Collective PEP
No
Product classification
  • Transportation of people or goods in buildings
  • Lifts or Elevators
Date of publication
2024/07/08
Date of end of validity
2029/07/08
Date of verification
2024/07/12
PCR
PEP-PCR-ed4-2021 09 06
PSR
No PSR
Use lifte time
25 years
Reference Product
ORONA NEXT SMART/SMART+ S19
Energy model used
Étape de fabrication : mix énergétique en Espagne - Ecoinvent 3.9 Étapes d'installation, d'utilisation et de désinstallation : mix énergétique en France - Ecoinvent 3.9
Total mass
4709.706 kg
Constitution
Plastic
0.63 %
29.33700 kg
Metal
77.00 %
3626.12000 kg
Other
22.37 %
1054.24700 kg
Covered products by list
- ORONA NEXT SMART/SMART+ S19
Functional Unit
1 t.km
Description
Le transport d’une charge sur une certaine distance, exprimée en tonnes (t) transportées sur un kilomètre (km), c’est-à-dire en tonnes-kilomètres (tkm) sur une trajectoire verticale ou inclinée.
Indicator Unit Total Manufacturing Distribution Installation Use End of Life Use
B1		 Maintenance
B2		 Repair
B3		 Replacement
B4		 Refurbishment
B5		 Operational energy use
B6		 Operational water use
B7		 Benefits and loads beyond the system boundaries
D
Climate change - total kg.eq.CO2 5.35E+1 4.18E+1 1.67E-1 7.63E-1 7.45E+0 3.29E+0 0 4.16E+0 0 0 0 3.3E+0 0 -1.09E+1
Climate change - fossil fuels kg.eq.CO2 5.29E+1 4.17E+1 1.67E-1 4.77E-1 7.35E+0 3.16E+0 0 4.13E+0 0 0 0 3.22E+0 0 -1.14E+1
Climate change - biogenics kg.eq.CO2 5.01E-1 -0E+0 1.51E-4 2.86E-1 9.14E-2 1.26E-1 0 2.09E-2 0 0 0 7.05E-2 0 4.63E-1
Climate change - land use and land use transformation kg.eq.CO2 1.17E-1 1.02E-1 8.1E-5 2.66E-4 1.11E-2 2.9E-3 0 8.89E-3 0 0 0 2.21E-3 0 -0.02E+0
Ozone depletion kg.eq.CFC-11 1.86E-6 1.53E-6 3.63E-9 1.08E-8 2.53E-7 6.48E-8 0 1.19E-7 0 0 0 1.34E-7 0 -2.64E-7
Acidification (AP) mole.eq.H+ 3.98E-1 3.33E-1 5.44E-4 1.65E-3 4.98E-2 1.32E-2 0 2.72E-2 0 0 0 2.26E-2 0 -0.05E+0
Freshwater eutrophication kg.eq.P 4.08E-3 3.45E-3 1.34E-6 5.11E-6 5.85E-4 2.96E-5 0 4.81E-4 0 0 0 1.05E-4 0 -0E+0
Marine aquatic eutrophication kg.eq.N 6.04E-2 4.67E-2 1.85E-4 5.59E-4 8.03E-3 4.91E-3 0 4.76E-3 0 0 0 3.28E-3 0 -0.01E+0
Terrestrial eutrophication mole.eq.N 6.85E-1 5.36E-1 1.98E-3 5.53E-3 8.91E-2 5.29E-2 0 5.33E-2 0 0 0 3.58E-2 0 -0.11E+0
Photochemical ozone formation kg.eq.NMVOC 2.55E-1 2.01E-1 8.13E-4 2.27E-3 3.21E-2 1.92E-2 0 2E-2 0 0 0 1.22E-2 0 -0.06E+0
Depletion of abiotic resources - elements kg.eq.Sb 5.69E-3 4.9E-3 5.36E-7 2.93E-6 7.75E-4 1.02E-5 0 6.23E-4 0 0 0 1.52E-4 0 -4.61E-5
Depletion of abiotic resources - fossil fuels MJ 1.1E+3 5.44E+2 2.37E+0 9.57E+0 4.93E+2 4.78E+1 0 5.35E+1 0 0 0 4.39E+2 0 -1.1E+2
Water requirement m³.eq.deprivation worldwide 1.75E+1 1.5E+1 9.64E-3 3.58E-2 2.23E+0 1.96E-1 0 1.03E+0 0 0 0 1.2E+0 0 -1.32E+0
Emission of fine particles incidence of diseases 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Ionizing radiation, human health kBq.eq.U235 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Ecotoxicity (fresh water) CTUe 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Human toxicity, carcinogenic effects CTUh 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Human toxicity, non-carcinogenic effects CTUh 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Impacts related to land use/soil quality - 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Use of renewable primary energy, excluding renewable primary energy resources used as raw materials MJ 1.29E+2 8.36E+1 3.67E-2 4.11E-1 4.31E+1 1.67E+0 0 5.91E+0 0 0 0 3.72E+1 0 -1.12E+1
Use of renewable primary energy resources used as raw materials MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Total use of renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 1.29E+2 8.36E+1 3.67E-2 4.11E-1 4.31E+1 1.67E+0 0 5.91E+0 0 0 0 3.72E+1 0 -1.12E+1
Use of non-renewable primary energy, excluding non-renewable primary energy resources used as raw materials MJ 1.08E+3 5.27E+2 2.37E+0 9.57E+0 4.93E+2 4.78E+1 0 5.35E+1 0 0 0 4.39E+2 0 -1.1E+2
Use of non-renewable primary energy resources used as raw materials MJ 1.68E+1 1.68E+1 0 0 0 0 0 0 0 0 0 0 0 0
Total use of non-renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 1.1E+3 5.44E+2 2.37E+0 9.57E+0 4.93E+2 4.78E+1 0 5.35E+1 0 0 0 4.39E+2 0 -1.1E+2
Use of secondary materials kg 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Use of renewable secondary fuels MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Use of non-renewable secondary fuels MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Net use of fresh water m³ 6.81E-1 5.08E-1 3.37E-4 2.06E-3 1.63E-1 8.01E-3 0 3.68E-2 0 0 0 1.26E-1 0 -0.06E+0
Total use of primary energy during the life cycle MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Hazardous waste disposed of kg 8.02E-1 2.4E-2 1.51E-5 4.2E-5 3.94E-2 7.38E-1 0 3.91E-2 0 0 0 2.84E-4 0 -0E+0
Non-hazardous waste disposed of kg 2.36E+1 1.73E+1 1.16E-1 3.52E-1 1.38E+0 4.45E+0 0 5.68E-1 0 0 0 8.12E-1 0 -1.63E+0
Radioactive waste disposed of kg 7.24E-3 1.3E-3 7.69E-7 4.53E-5 5.81E-3 8.95E-5 0 1.13E-4 0 0 0 5.7E-3 0 3.08E-5
Components for re-use kg 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Materials for recycling kg 8.75E+0 5.06E-1 0 4.22E-1 1.13E-1 7.71E+0 0 1.13E-1 0 0 0 0 0 0
Materials for energy recovery kg 1.28E+0 0 0 1.51E-1 0 1.13E+0 0 0 0 0 0 0 0 0
Exported energy MJ by energy vector 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Biogenic carbon content of the product kg of C 7.62E-2 7.62E-2 0 0 0 0 0 0 0 0 0 0 0 0
Biogenic carbon content of the associated packaging kg of C 3.07E-1 3.07E-1 0 0 0 0 0 0 0 0 0 0 0 0
Functional Unit
1 unit
Description
Le produit de référence est l'ascenseur Orona Next Smart/Smart+ S19 avec 5 arrêts et 1000 kg, ce qui équivaut à 377,26 tkm.
Indicator Unit Total Manufacturing Distribution Installation Use End of Life Use
B1		 Maintenance
B2		 Repair
B3		 Replacement
B4		 Refurbishment
B5		 Operational energy use
B6		 Operational water use
B7		 Benefits and loads beyond the system boundaries
D
Climate change - total kg.eq.CO2 2.02E+4 1.58E+4 6.31E+1 2.88E+2 2.81E+3 1.24E+3 0 1.57E+3 0 0 0 1.24E+3 0 -4.13E+3
Climate change - fossil fuels kg.eq.CO2 1.99E+4 1.57E+4 6.3E+1 1.8E+2 2.77E+3 1.19E+3 0 1.56E+3 0 0 0 1.22E+3 0 -4.29E+3
Climate change - biogenics kg.eq.CO2 1.89E+2 -0.68E+0 5.69E-2 1.08E+2 3.45E+1 4.74E+1 0 7.89E+0 0 0 0 2.66E+1 0 1.75E+2
Climate change - land use and land use transformation kg.eq.CO2 4.4E+1 3.86E+1 3.06E-2 1.01E-1 4.19E+0 1.1E+0 0 3.35E+0 0 0 0 8.32E-1 0 -7E+0
Ozone depletion kg.eq.CFC-11 7.03E-4 5.78E-4 1.37E-6 4.08E-6 9.53E-5 2.45E-5 0 4.49E-5 0 0 0 5.04E-5 0 -9.96E-5
Acidification (AP) mole.eq.H+ 1.5E+2 1.26E+2 2.05E-1 6.23E-1 1.88E+1 4.99E+0 0 1.03E+1 0 0 0 8.52E+0 0 -1.7E+1
Freshwater eutrophication kg.eq.P 1.54E+0 1.3E+0 5.04E-4 1.93E-3 2.21E-1 1.12E-2 0 1.81E-1 0 0 0 3.95E-2 0 -0.2E+0
Marine aquatic eutrophication kg.eq.N 2.28E+1 1.76E+1 6.98E-2 2.11E-1 3.03E+0 1.85E+0 0 1.79E+0 0 0 0 1.24E+0 0 -3.78E+0
Terrestrial eutrophication mole.eq.N 2.58E+2 2.02E+2 7.46E-1 2.09E+0 3.36E+1 1.99E+1 0 2.01E+1 0 0 0 1.35E+1 0 -4.27E+1
Photochemical ozone formation kg.eq.NMVOC 9.63E+1 7.58E+1 3.07E-1 8.55E-1 1.21E+1 7.25E+0 0 7.53E+0 0 0 0 4.6E+0 0 -2.28E+1
Depletion of abiotic resources - elements kg.eq.Sb 2.15E+0 1.85E+0 2.02E-4 1.1E-3 2.92E-1 3.86E-3 0 2.35E-1 0 0 0 5.73E-2 0 -0.02E+0
Depletion of abiotic resources - fossil fuels MJ 4.14E+5 2.05E+5 8.93E+2 3.61E+3 1.86E+5 1.8E+4 0 2.02E+4 0 0 0 1.66E+5 0 -4.16E+4
Water requirement m³.eq.deprivation worldwide 6.59E+3 5.65E+3 3.64E+0 1.35E+1 8.41E+2 7.39E+1 0 3.89E+2 0 0 0 4.52E+2 0 -4.98E+2
Emission of fine particles incidence of diseases 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Ionizing radiation, human health kBq.eq.U235 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Ecotoxicity (fresh water) CTUe 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Human toxicity, carcinogenic effects CTUh 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Human toxicity, non-carcinogenic effects CTUh 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Impacts related to land use/soil quality - 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Use of renewable primary energy, excluding renewable primary energy resources used as raw materials MJ 4.86E+4 3.15E+4 1.38E+1 1.55E+2 1.63E+4 6.3E+2 0 2.23E+3 0 0 0 1.4E+4 0 -4.23E+3
Use of renewable primary energy resources used as raw materials MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Total use of renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 4.86E+4 3.15E+4 1.38E+1 1.55E+2 1.63E+4 6.3E+2 0 2.23E+3 0 0 0 1.4E+4 0 -4.23E+3
Use of non-renewable primary energy, excluding non-renewable primary energy resources used as raw materials MJ 4.07E+5 1.99E+5 8.93E+2 3.61E+3 1.86E+5 1.8E+4 0 2.02E+4 0 0 0 1.66E+5 0 -4.16E+4
Use of non-renewable primary energy resources used as raw materials MJ 6.32E+3 6.32E+3 0 0 0 0 0 0 0 0 0 0 0 0
Total use of non-renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 4.14E+5 2.05E+5 8.93E+2 3.61E+3 1.86E+5 1.8E+4 0 2.02E+4 0 0 0 1.66E+5 0 -4.16E+4
Use of secondary materials kg 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Use of renewable secondary fuels MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Use of non-renewable secondary fuels MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Net use of fresh water m³ 2.57E+2 1.92E+2 1.27E-1 7.78E-1 6.14E+1 3.02E+0 0 1.39E+1 0 0 0 4.75E+1 0 -2.15E+1
Total use of primary energy during the life cycle MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Hazardous waste disposed of kg 3.02E+2 9.04E+0 5.68E-3 1.58E-2 1.49E+1 2.78E+2 0 1.48E+1 0 0 0 1.07E-1 0 -0.49E+0
Non-hazardous waste disposed of kg 8.89E+3 6.52E+3 4.36E+1 1.33E+2 5.2E+2 1.68E+3 0 2.14E+2 0 0 0 3.06E+2 0 -6.13E+2
Radioactive waste disposed of kg 2.73E+0 4.89E-1 2.9E-4 1.71E-2 2.19E+0 3.38E-2 0 4.26E-2 0 0 0 2.15E+0 0 1.16E-2
Components for re-use kg 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Materials for recycling kg 3.3E+3 1.91E+2 0 1.59E+2 4.26E+1 2.91E+3 0 4.26E+1 0 0 0 0 0 0
Materials for energy recovery kg 4.83E+2 0 0 5.7E+1 0 4.26E+2 0 0 0 0 0 0 0 0
Exported energy MJ by energy vector 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Biogenic carbon content of the product kg of C 2.88E+1 2.88E+1 0 0 0 0 0 0 0 0 0 0 0 0
Biogenic carbon content of the associated packaging kg of C 1.16E+2 1.16E+2 0 0 0 0 0 0 0 0 0 0 0 0
