ABBG-00230-V01.01

Download the PEP PDF
Name of the PEP
Piping materials - AJI Bushing flange and insulators
Trademark / Owner
ABB ASEA BROWN BOVERI
ABB ASEA BROWN BOVERI LTD
Collective PEP
No
Product classification
  • Installation wiring devices for electric power and communication networks (≤ 63 amperes)
  • Miscellenaeous
Geographical validity area
europe / FIN / SWE
Date of publication
2023/05/01
Date of end of validity
2028/05/01
Date of verification
2023/10/27
PCR
PEP-PCR-ed4-2021 09 06
PSR
PSR-0005-ed2-2016 03 29
Use lifte time
20 years
Reference Product
2TKA160001G1 - AJI10
Energy model used
Manufacturing: Estonia national electric mix Installation: Based on sales mix (see geographical representativeness) Use: Non-applicable End of life: Based on sales mix (see geographical representativeness)
Total mass
0.026 kg
Constitution
Plastic
61.90 %
0.01600 kg
Metal
28.50 %
0.00700 kg
Other
9.60 %
0.00300 kg
Comments
The reference product and other products in this range are in conformity with the provisions of Low Voltage Directive 2014/35/EU, and nationaI legislation. Plastic used for the reference product are halogen-free materiaIs (IEC/61249-2-21) and they are aIso recyclable.
Covered products by list
- 2TKA001630G1 - AJI7
- 2TKA001632G1 - AJI9
- 2TKA001624G1 - AJI52
- 2TKA001625G1 - AJI54
- 2TKA001627G1 - AJI61
- 2TKA160001G1 - AJI10
- 2TKA160004G1 - AJI15
- 2TKA160005G1 - AJI55
- 2TKA160032G1 - AJI11
- 2TKA160033G1 - AJI53
- 2TKA001629G1 - AJI63
- 2TKA001620G1 - AJI12
- 2TKA001628G1 - AJI62
- 2TKA160031G1 - AJI6
- 2TKA160003G1 - AJI14
- 2TKA160002G1 - AJI13
- 2TKA001626G1 - AJI60
Functional Unit
1 unit
Description
Protect persons during 20 years against direct contact with live parts and allow grouping monitoring, control, and protection devices in a single enclosure or a cabinet having the following dimensions (Ø 20 mm x 45 mm x 36 mm).
Indicator Unit Total Manufacturing Distribution Installation Use End of Life Use
B1		 Maintenance
B2		 Repair
B3		 Replacement
B4		 Refurbishment
B5		 Operational energy use
B6		 Operational water use
B7		 Benefits and loads beyond the system boundaries
D
Climate change - total kg.eq.CO2 1E-1 8.79E-2 1.62E-3 3.24E-4 00E+0 1.02E-2 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 4.46E-3
Climate change - fossil fuels kg.eq.CO2 9.97E-2 8.76E-2 1.62E-3 3.21E-4 00E+0 1.02E-2 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 4.43E-3
Climate change - biogenics kg.eq.CO2 2.58E-4 2.41E-4 4.7E-7 2.33E-6 00E+0 1.39E-5 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 5.19E-5
Climate change - land use and land use transformation kg.eq.CO2 1.4E-4 1.3E-4 7E-7 1.78E-7 00E+0 8.94E-6 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -1.4E-5
Ozone depletion kg.eq.CFC-11 6.08E-9 4.99E-9 3.75E-10 3.97E-11 00E+0 6.75E-10 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -4.72E-10
Acidification (AP) mole.eq.H+ 5E-4 4.61E-4 6.75E-6 1.16E-6 00E+0 3.11E-5 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -7.26E-5
Freshwater eutrophication kg.eq.P 3.83E-5 3.56E-5 1.05E-7 2.77E-8 00E+0 2.59E-6 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -5.7E-6
Marine aquatic eutrophication kg.eq.N 1E-4 9.03E-5 1.42E-6 4.15E-7 00E+0 8.28E-6 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -7.09E-6
Terrestrial eutrophication mole.eq.N 9.97E-4 8.98E-4 1.56E-5 4.12E-6 00E+0 7.94E-5 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -0E+0
Photochemical ozone formation kg.eq.NMVOC 3.07E-4 2.82E-4 3.97E-6 1E-6 00E+0 2.04E-5 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -4.32E-5
Depletion of abiotic resources - elements kg.eq.Sb 8.45E-7 7.77E-7 5.63E-9 1.62E-9 00E+0 6.06E-8 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -2.46E-7
Depletion of abiotic resources - fossil fuels MJ 2.1E+0 1.96E+0 2.45E-2 3.37E-3 00E+0 1.09E-1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -0.57E+0
Water requirement m³.eq.deprivation worldwide 5.95E-2 5.62E-2 7.31E-5 3.54E-5 00E+0 3.22E-3 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -0.01E+0
Use of renewable primary energy, excluding renewable primary energy resources used as raw materials MJ 1.91E-1 1.81E-1 3.44E-4 1.3E-4 00E+0 9.77E-3 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -0.03E+0
Total use of renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 1.91E-1 1.81E-1 3.44E-4 1.3E-4 00E+0 9.77E-3 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -0.03E+0
Use of non-renewable primary energy, excluding non-renewable primary energy resources used as raw materials MJ 7.83E-5 6.97E-5 1.08E-6 2E-7 00E+0 7.27E-6 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -6.02E-6
Use of non-renewable primary energy resources used as raw materials MJ 2.23E+0 2.09E+0 2.6E-2 3.58E-3 00E+0 1.15E-1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -0.6E+0
Total use of non-renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 2.23E+0 2.09E+0 2.6E-2 3.58E-3 00E+0 1.15E-1 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -0.6E+0
Net use of fresh water m³ 1.25E-3 1.17E-3 2.9E-6 1.13E-6 00E+0 7.2E-5 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -0E+0
Hazardous waste disposed of kg 9.7E-6 9.49E-6 6.23E-8 8.17E-9 00E+0 1.41E-7 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -7.25E-7
Non-hazardous waste disposed of kg 3.13E-2 1.13E-2 1.23E-3 1.74E-3 00E+0 1.7E-2 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -0E+0
Radioactive waste disposed of kg 4.23E-6 3.47E-6 1.66E-7 1.98E-8 00E+0 5.7E-7 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 -9.17E-7
Materials for recycling kg 1.52E-2 00E+0 00E+0 1.6E-3 00E+0 1.36E-2 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0 00E+0
