SPRE-00002-V01.01

Download the PEP PDF Extrapolation Rules
Name of the PEP
SPRECON-E-P
Trademark / Owner
SPRECHER AUTOMATION
SPRECHER AUTOMATION
Collective PEP
No
Product classification
  • Installation wiring devices for electric power and communication networks (≤ 63 amperes)
  • Miscellenaeous
Date of publication
2025/05/01
Date of end of validity
2030/05/01
Date of verification
2025/10/02
PCR
PEP-PCR-ed4-2021 09 06
PSR
PSR-0005-ed3.1-2023 12 08
Use life time
10 years
Reference Product
SPRECON-E-P
Energy model used
Germany
Total mass
5.699 kg
Constitution
Plastic
0.50 %
0.02600 kg
Metal
43.10 %
2.22900 kg
Other
56.40 %
2.91700 kg
Covered products by list
- SPRECON-E-P DDx6-1 24 HP Case
- SPRECON-E-P DDx6-1 40 HP Case
- SPRECON-E-P DDx6-2 40 HP Case
- SPRECON-E-P DSx6-0 24 HP Case
- SPRECON-E-P DSx6-1 24 HP Case
- SPRECON-E-P DSx6-1 40 HP Case
- SPRECON-E-P DSx6-2 40 HP Case
- SPRECON-E-P D2Q6-1 40 HP Case
- SPRECON-E-P D2Q6-2 40 HP Case
- SPRECON-E-P D3Q6-1 40 HP Case
- SPRECON-E-P D3Q6-2 40 HP Case
- SPRECON-E-P D3Qpi6-1 40 HP Case
- SPRECON-E-P D3Qpi6-2 40 HP Case
- SPRECON-E-P DLx6-1 24 HP Case
- SPRECON-E-P DLx6-1 40 HP Case
- SPRECON-E-P DLx6-2 40 HP Case
- SPRECON-E-P RSx6-2 40 HP Case
- SPRECON-E-P RSx6-2 80 HP Case
- SPRECON-E-P
Functional Unit
1 unit
Description
The primary task of the SPRECON-E-P series is to protect equipment and ensure security of supply. The device series is designed for maximum security, reliability and availability. Various SPRECON-E-P devices are available for different applications, for example for motor protection, protection of decentralized feeders, protection of neutral points, transformers or high-voltage lines.
Extrapolation Rules
The calculation of the factors for the Upstream, Core and most Downstream modules are based on the changes in components. The extrapolation for all weight-based life cycle stages are calculated based on weight and emission factors of similar components in the reference product. The calculation for the use phase is based on the change in actual electricity consumption.
Indicator Unit Total Manufacturing Distribution Installation Use End of Life Use
B1		 Maintenance
B2		 Repair
B3		 Replacement
B4		 Refurbishment
B5		 Operational energy use
B6		 Operational water use
B7		 Benefits and loads beyond the system boundaries
D
Climate change - total kg.eq.CO2 7.86E+2 1.9E+2 1.12E+0 1.11E-1 5.92E+2 2.8E+0 0 0 0 0 0 5.92E+2 0 -3.27E+0
Climate change - fossil fuels kg.eq.CO2 7.76E+2 1.89E+2 1.12E+0 1.11E-1 5.83E+2 2.8E+0 0 0 0 0 0 5.83E+2 0 -3.24E+0
Climate change - biogenics kg.eq.CO2 8.24E+0 4.09E-1 3.26E-4 2.01E-1 7.62E+0 1.13E-3 0 0 0 0 0 7.62E+0 0 -0E+0
Climate change - land use and land use transformation kg.eq.CO2 1.4E+0 4.21E-1 5.51E-4 4.9E-5 9.73E-1 1.15E-3 0 0 0 0 0 9.73E-1 0 -0.02E+0
Ozone depletion kg.eq.CFC-11 1.34E-5 6.57E-6 2.43E-8 2.17E-9 6.77E-6 3.4E-8 0 0 0 0 0 6.77E-6 0 -8.06E-8
Acidification (AP) mole.eq.H+ 3.32E+0 1.62E+0 2.44E-3 2.26E-4 1.7E+0 4.52E-3 0 0 0 0 0 1.7E+0 0 -0.06E+0
Freshwater eutrophication kg.eq.P 1.05E-1 1.66E-2 9.06E-6 8.14E-7 8.84E-2 2.58E-5 0 0 0 0 0 8.84E-2 0 -0E+0
Marine aquatic eutrophication kg.eq.N 4.98E-1 2.29E-1 6.01E-4 5.77E-5 2.68E-1 1.13E-3 0 0 0 0 0 2.68E-1 0 -0E+0
Terrestrial eutrophication mole.eq.N 6.04E+0 2.64E+0 6.26E-3 6.01E-4 3.38E+0 1.21E-2 0 0 0 0 0 3.38E+0 0 -0.05E+0
Photochemical ozone formation kg.eq.NMVOC 2.1E+0 1.13E+0 3.79E-3 3.47E-4 9.62E-1 5.21E-3 0 0 0 0 0 9.62E-1 0 -0.02E+0
Depletion of abiotic resources - elements kg.eq.Sb 1.12E+4 2.47E+3 1.58E+1 1.41E+0 8.73E+3 1.9E+1 0 0 0 0 0 8.73E+3 0 -3.81E+1
Depletion of abiotic resources - fossil fuels MJ 3.58E-2 2.93E-2 3.65E-6 3.21E-7 6.49E-3 5.9E-6 0 0 0 0 0 6.49E-3 0 -0E+0
Water requirement m³.eq.deprivation worldwide 8.94E+1 4.57E+1 6.53E-2 7.42E-3 4.34E+1 2.25E-1 0 0 0 0 0 4.34E+1 0 -0.8E+0
Emission of fine particles incidence of diseases 1.99E-5 1.2E-5 8.28E-8 7.41E-9 7.65E-6 9.48E-8 0 0 0 0 0 7.65E-6 0 -2.78E-7
Ionizing radiation, human health kBq.eq.U235 4.06E+1 8.15E+0 8.03E-3 7.11E-4 3.24E+1 2.28E-2 0 0 0 0 0 3.24E+1 0 -0.09E+0
Ecotoxicity (fresh water) CTUe 5.36E+3 2.92E+3 7.84E+0 7.44E-1 2.41E+3 2.32E+1 0 0 0 0 0 2.41E+3 0 -4.94E+1
Human toxicity, carcinogenic effects CTUh 6E-7 3.83E-7 5.09E-10 4.83E-11 2.15E-7 8.14E-10 0 0 0 0 0 2.15E-7 0 -2.01E-8
Human toxicity, non-carcinogenic effects CTUh 2.02E-5 1.1E-5 1.12E-8 1.11E-9 9.21E-6 3.97E-8 0 0 0 0 0 9.21E-6 0 -8.04E-7
Impacts related to land use/soil quality - 3.5E+3 1.34E+3 9.58E+0 8.75E-1 2.14E+3 1.11E+1 0 0 0 0 0 2.14E+3 0 -1.91E+1
Use of renewable primary energy, excluding renewable primary energy resources used as raw materials MJ 2.82E+3 3.07E+2 2.49E-1 2.21E-2 2.51E+3 7.42E-1 0 0 0 0 0 2.51E+3 0 -5.35E+0
Use of renewable primary energy resources used as raw materials MJ 7.27E+0 7.27E+0 0 0 0 0 0 0 0 0 0 0 0 0
Total use of renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 2.83E+3 3.14E+2 2.49E-1 2.21E-2 2.51E+3 7.42E-1 0 0 0 0 0 2.51E+3 0 -5.35E+0
Use of non-renewable primary energy, excluding non-renewable primary energy resources used as raw materials MJ 1.2E+4 2.63E+3 1.68E+1 1.5E+0 9.35E+3 2.02E+1 0 0 0 0 0 9.35E+3 0 -4.02E+1
Use of non-renewable primary energy resources used as raw materials MJ 3.02E+0 3.02E+0 0 0 0 0 0 0 0 0 0 0 0 0
Total use of non-renewable primary energy resources (primary energy and primary energy resources used as raw materials) MJ 1.2E+4 2.64E+3 1.68E+1 1.5E+0 9.35E+3 2.02E+1 0 0 0 0 0 9.35E+3 0 -4.02E+1
Use of secondary materials kg 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Use of renewable secondary fuels MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Use of non-renewable secondary fuels MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Net use of fresh water m³ 6E+0 1.66E+0 2.28E-3 2.44E-4 4.33E+0 7.94E-3 0 0 0 0 0 4.33E+0 0 -0.05E+0
Total use of primary energy during the life cycle MJ 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Hazardous waste disposed of kg 7.64E-2 2.76E-2 0 0 0 4.88E-2 0 0 0 0 0 0 0 4.88E-2
Non-hazardous waste disposed of kg 2.92E+0 8.33E-1 1.67E-5 1.36E-1 1.03E-2 1.94E+0 0 0 0 0 0 1.03E-2 0 1.94E+0
Radioactive waste disposed of kg 3.13E-8 3.13E-8 0 0 0 0 0 0 0 0 0 0 0 0
Components for re-use kg 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Materials for recycling kg 5.26E+0 1.67E+0 0 3.91E-1 0 3.19E+0 0 0 0 0 0 0 0 0
Materials for energy recovery kg 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Exported energy MJ by energy vector 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Biogenic carbon content of the product kg of C 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Biogenic carbon content of the associated packaging kg of C 2.01E-1 2.01E-1 0 0 0 0 0 0 0 0 0 0 0 0
